Overview



Compact and fully featured, the Simage Integrator series can easily be integrated into industrial applications from electricity meters to intrusion alarms or vending machines. Simage Integrator modems are GPRS quadband and full type approved, making them immediately usable worldwide. Renowned for their outstanding reliability, Simage Integrator modems are the perfect devices to integrate into each of your projects facing tough conditions or extended lifetime requirements.

General Features



Technology
GSM    Quadband
GPRS    Class 10
Voice/Data/Fax/SMS
TCP/IP    Full TCP/IP Stack


Interfaces
SIM Plug-in card reader    1.8/3 V.
RS232 on 15 pin Sub-D connector
Pin power supply connector    4 pin DC
SMA antenna connector (50 ohm)


Power Supply
Input voltage    6 to 32V DC


Power Consumption
GSM 850/900 (PCL 5)    203mA at 6V
DCS 1800/PCS 1900 (PCL0)    140mA at 6V
GPRS 850/900 CL10 (PCL5)    388mA at 6V
GPRS 1800/1900 CL10 (PCL0)    232mA at 6V
Idle consumption    45mA at 6V
Idle consumption (RS232 not connected)    18mA at 6V
Sleep Mode    4mA at 6V


CERTIFICATIONS/COMPLIANCES
CE, GCF, RoHS Certification


VOICE, DATA AND SMS FEATURES
Data circuit asynchronous, transparent and non-transparent up to 14,400 bit/s ; Automatic fax group 3 (Class 1 and Class 2) ; MNP2, V.42bis ; Text and PDU SMS ; Point to point SMS (MT/MO) ; UCS2 Character Set Management


FUNCTIONAL FEATURES
AT command set (GSM 07.05, GSM 07.07 and Wavecom )    > 300

FEATURES/PRODUCTS
                                                       Integrator Crystal   Integrator Lite   Integrator IP   Integrator Advanced
Input - Digital                                            N/A                          1                         1                            1
Input - Analog                                                                                         N/A                                     1
Download Over The Air                                            N/A                                           Optional
Autorestore - timer reset
Other Features
Operating status LED
Casing    Plastic    Metal

Dimensions
Size (mm)                                             88x60x26                                        90x72x23
Weight (g)                                                    70                                                   100
Temperature Range
Operating / Storage                                                 -30~+75 ˚C / -40~+85 ˚C                 30~+85 ˚C / -40~+85 ˚C

OPTIONAL ACCESSORIES (ADDITIONAL ACCESSORIES ARE ALSO AVAILABLE UPON REQUEST)
GSM antenna 900/1800 Mhz
GSM antenna 850/1900 Mhz
RS232 cable interface
Din Clip (metal casing only)    N/A
